Multifunction Power Quality Meter

HC6010

Download Add Inquiry
From the LCD(new design)/VFD(Old) multi-display reading are V,A, VA, W, Var, WH, etc. more than 30 power and energy parameters. Via the RS 485 Modbus, communications, including the instant maximum and minimum of all parameter, maximum demand control, time stamping, etc. more than 90 parameters can be achieved by remote monitoring system.

This power meter can replace many units of conventional analog or digital instruments and change over switches (e.g. Amp, Volt, KVA, KW, PF, KWH, KVarH, FQ etc.). This saves on the wiring material usage and reduces the cost on metering needs.


Up to 0.15% accuracy, the HC6010 power meter measures, via the RS 485 Modbus, instant maximum and minimum of all parameter, maximum demand control, time stamping, etc. more than 90 parameters can be achieved by remote monitoring system.

Features

  • Accuracy up to 0.15%
  • Over 90 power and energy parameters
  • For factory and building automation
  • Modbus RTU / DNP3.0 protocol
  • Maximum 600V auto range 10~600V
  • Low input burden 0.2VA (5A/120V)
  • Power supply range 80-260V AC/DC
  • True RMS conversion
  • Instant maximum and minimum" "VFD display clear and long life
  • Built in RTC (real time clock)
  • Field programmable PT/CT ratio
  • Maximum demand control applicable
  • “User Map” speed up communication
  • Memory for all setup and energy data
  • Comprehensive self test diagnostics
  • 2KV, RMS input/output/power isolation
  • Compatible for DIN & ANSI cut out

Accuracy

  • 0.15%fs for V x 3
  • 0.15%fs for A x 3
  • 0.25%fs for Watts
  • 0.25%fs for Vars
  • 0.25%fs for VA
  • 0.25%fs* for PF
  • 0.8%rd* for WH
  • 1%rd* for VarH
  • 0.5%fs for IO(AO)
  • 0.03%rd for Hz
  • 0.25%fs for Watt demand
  • 0.15%fs for Amper demand
  • Harmonic: 15th
  • * Accuracy performance range for WH/VarH/PF, Cosθ : 1-0.5 for WH/PF, Sinθ : 1-0.5 for VarH, Voltage≧75V, Current≧10% of rating

Certifications

  • CE
