• 特色 ：
  • 高速4G LTE 網路LTE
  • Cat.4, 2T2R MIMO 對下提供150M 對上提供50M
  • 相容於4G/3G/2G 大哥大網路LTE-E:
  • FDD B1/3/5/7/8/20 (2100/1800/850/2600/900/800MHz)
  • TDD B38/40/41 (2600/2300/2500MHz)
• LTE-U:
  • FDD B2/B4/B12 (1900/1700/700MHz)
  • 堅固的設計用於路邊監控與ITS應用
  • 有效的散熱設計可在-40~70oC環境運轉
  • CE認證
  • IEC61000-6-4/EN61000-4-4/EN61000-4-18 電磁干擾保護
  • 加強型資安管理
  • 支持通訊分類的防火牆管理
  • DMZ, port forwarding, NAT for LAN protection
  • HTTPs/SSH 安管登入
  • 管理特色
  • 不同的規畫路徑,包括Web GUI, Telnet
  • 軟體可選擇規劃  RS232/422/485
  • 串行通訊和高吞吐量數據交換
  • 雙串列口，帶RS232 / 422/485全功能串行LTE數據交換
  • 2個全Gigabit 乙太網交換接口

• Technology
• Standard : 3GPP Release 11 Long Term Evolution (LTE), fallback 3GPP Release 7,8,9 for HSPA/UMTS
• IEEE 802.3u 100Base-TX Fast Ethernet
• IEEE 802.3ab 1000Base-T Gigabit Ethernet copper
• Interface
• Ethernet Port : 2 x 100/1000MBase-T RJ45, Auto Negotiation
• System LED : 1 x PWR: Green ON
• 1 x SYS: Ready: (Green On), Firmware Updating: (Green Blinking)
• 1 x DO: Red On
• 2 x Ethernet Ports: Green ON, Green Blinking while activating
• 2 x Serial Ports: Green Blinking while transmitting data
• 3 x Radio (Ra, Rb, Rc): Radio status, check manual for detail information
• USB : 1 x USB reserved for Configuration/Firmware Update
• Reset : System Reset(2~6 Seconds) / Default Settings Reset(over 7 Seconds)
• SMA Socket : 2 x RP-SMA Female
• SIM Socket : 1 x Nano SIM slot
• SD : SD for field diagnostic data logging
• Serial : 2 x RS232/422/485, DB9
• Power Input, Digital Output : 6-Pin Removable Terminal Block Connector
• 4 Pin for Redundant Power
• 2 Pin for DO (Relay Alarm)
• DO: Dry Relay Output with 0.5A/24V DC
• Cellular Properties
• Standard : GSM/GPRS/EDGE 3GPP Release 6 UMTS/HSPA 3GPP Release 8 LTE 3GPP Release 11
• Data Rate : GPRS: DL: max. 85.6 kbps, UL: max. 85.6 kbps
• EDGE: DL: max. 236.8 kbps, UL: max. 236.8 kbps HSPA: DL: max. 42 Mbps, UL: max. 5.76 Mbps LTE-FDD Cat.4: DL: max. 150 Mbps, UL: max. 50 Mbps, 2x2 DL MIMO
• LTE-TDD Cat.4: DL: max. 130 Mbps, UL: max. 35 Mbps, 2x2 DL MIMO
• Band Information: LTE-E:  LTE: FDD B1/B3/B5/B7/B8/B20 (2100/1800/850/2600/900/800MHz)
• LTE: TDD B38/B40/B41 (2600/2300/2500MHz)
• WCDMA: FDD B1/B5/B8 (2100/850/900MHz) GSM: B3/B8 (1800/900MHz )
• Band Information: LTE-U : LTE: FDD B2/B4/B12 (1900/1700/700MHz)
• WCDMA: B2/B4/B5 (1900/1700/850MHz)
• Power Requirement
• Input Voltage : 24V (12~48VDC)
• Reverse Polarity Protect : Yes
• Input Current : 0.23A@24V
• Power Consumption : Max 5.52W@24VDC full traffic, suggest to reserve 15% tolerance
• Software
• Management Interface : CGI WebGUI, Telnet
• Time Management : SNTP, Cellular Time
• Network Management : IPv4, DHCP server/client
• Traffic Management : NAT Routing, Traffic shaping
• Security : Firewall, DMZ, Port Forwarding, HTTPs, SSH
• Cellular Configuration : Radio on/off, 4G LTE/3G HSPA Configuration, SIM Security, Connection
• Mechanical
• Installation : DIN Rail
• Enclosure Material : Steel Metal with Aluminum
• Dimension : 50 x 151 x 120 mm(W x H x D) / without DIN Rail Clip, To be checked
• Ingress Protection : IP30
• Environmental
• Operating Temperature & Humidity : -40°C~70°C , 5%~95% Non- Condensing
• Storage Temperature : -40°C~85°C
• MTBF :  >200,000 hours

認證

• FCC
• CE
